1、 Pipeline impact

1.中高层建筑的国产精品伦一区二区三级视频99无码熟妇丰满人妻啪啪。中层建筑的厨房都都是使用同一个国产精品伦一区二区三级视频99无码熟妇丰满人妻啪啪。所以厨房里的油渍会通过99无码熟妇丰满人妻啪啪传到外面。靠近主99无码熟妇丰满人妻啪啪的那些楼层，家里厨房国产精品伦一区二区三级视频效果比较好。因为没有其他影响，而且对于那些远离主通道的厨房，国产精品伦一区二区三级视频会更差。

1. Smoke exhaust pipe of middle and high rise buildings. The kitchens of middle rise buildings all use the same smoke exhaust pipe. So the oil stain in the kitchen will be transmitted to the outside through the pipeline. For those floors near the main pipe, the kitchen smoke exhaust effect is better. Because there is no other impact, and for those kitchens far away from the main passage, the smoke will be worse.

2.低层建筑的国产精品伦一区二区三级视频99无码熟妇丰满人妻啪啪。在这种类型的厨房里，可以选择在两面墙之间设计一个国产精品伦一区二区三级视频口，可以完全顺畅的国产精品伦一区二区三级视频。

2. Smoke exhaust pipes of low rise buildings. In this type of kitchen, you can choose to design a smoke vent between two walls, which can completely smooth smoke exhaust.

3.高层建筑的国产精品伦一区二区三级视频99无码熟妇丰满人妻啪啪。高层厨房国产精品伦一区二区三级视频管要求较高，厨房国产精品伦一区二区三级视频高度应设计在2.4米以上。厨房国产精品伦一区二区三级视频设计出口，可以设计一个直径一般在170-200mm的圆孔，这样会保证厨房的油渍顺利干净的离开厨房。

3. Smoke exhaust pipe of high-rise buildings. The smoke exhaust pipe of high-rise kitchen is required to be high, and the smoke exhaust height of the kitchen should be designed to be more than 2.4 meters. A circular hole with a diameter of 170-200mm can be designed for the kitchen smoke exhaust design outlet, which will ensure that the oil stains in the kitchen leave the kitchen smoothly and cleanly.

二、送风和排风出口布置

2、 Layout of air supply and exhaust outlets

在安装济南厨房国产精品伦一区二区三级视频99无码熟妇丰满人妻啪啪的进风口和出风口时，应根据炊具的具体位置来考虑，不要让送风射流干扰炊具的排气通风。在确定送风出口的出口风速时，区域风速在距地面2m左右时为0.25m/s。送风口应沿排风罩方向布置，距排风罩前方0.7m，出风口离排风罩越远越好。

When installing the air inlet and outlet of the smoke exhaust pipe in Jinan kitchen, it should be considered according to the specific locations of the cooker, and the air supply jet should not interfere with the exhaust ventilation of the cooker. When determining the outlet wind speed of the air supply outlet, the regional wind speed is 0.25m/s when it is about 2m from the ground. The air supply outlet shall be arranged along the direction of the exhaust hood, 0.7m away from the front of the exhaust hood. The air outlet shall be as far away as possible from the exhaust hood.

三、国产精品伦一区二区三级视频99无码熟妇丰满人妻啪啪设计

3、 Smoke exhaust pipe design

厨房国产精品伦一区二区三级视频管水平段不宜过长。水平距离一般不超过15m，坡度应大于2%。水平端应配有柔性接头，以便于油垢。根据规范，排气速度不应低于10m/s，以防止因风速低而导致油粘附在烟道上。连接到排气罩的支管应配备一个风量控制阀。

The horizontal section of kitchen smoke exhaust pipe should not be too long. The horizontal distance shall not exceed 15m generally, and the gradient shall be greater than 2%. The horizontal end shall be provided with flexible joints to facilitate the removal of oil dirt. According to the specification, the exhaust speed shall not be less than 10m/s to prevent oil from adhering to the flue due to low wind speed. The branch pipe connected to the exhaust hood shall be equipped with an air volume control valve.
